| SIZE | PR | Overall Diameter (mm) | Section Width (mm) | Rim | Max.load | Relative Pressure | Pattern |
| (kgs) | (kpa) | ||||||
| 7.50-16 | 8 | 810 | 205 | 5.50E | 650 | 250 | E3/L3A |
| 8.25-16 | 10 | 885 | 235 | 6.50H | 970 | 280 | E3/L3A |
| 9.00-16 | 10 | 834 | 225 | 6.50H | 1080 | 310 | E3/L3A |
| 9.00-20 | 14 | 1018 | 259 | 7.0 | 2500 | 810 | E3/L3A |
| 10.00-16 | 12 | 910 | 275 | W8L | 1090 | 310 | E3/L3A |
| 11.00-16 | 12 | 970 | 315 | W10L | 1060 | 310 | E3/L3A |
| 12.00-16 | 12 | 884 | 244 | 8.5 | 1100 | 320 | E3/L3A |
| 14/90-16 | 12 | 896 | 215 | 8.5H | 1245 | 290 | E3/L3A |
| 16/70-16 | 14 | 870 | 260 | 8.5H | 1055 | 390 | E3/L3A |
| 16/90-16 | 14 | 870 | 260 | 8.5H | 1055 | 390 | E3/L3A |
| 16/70-20 | 16 | 1075 | 410 | 13.00 | 3375 | 350 | E3/L3A |
| 16/70-24 | 16 | 1175 | 410 | 13.00 | 3350 | 450 | E3/L3A |
| 205/70-16 | 14 | 1075 | 410 | 8.5H | 2850 | 350 | E3/L3A |
| 23.5-16 | 14 | 1075 | 410 | 8.5H | 2850 | 350 | E3/L3A |
| 17.5-25 | 16 | 1350 | 445 | 14.00/1.5 | 7300 | 475 | E3/L3A |
| 20.5-25 | 20 | 1490 | 520 | 17.00/2.0 | 9500 | 450 | E3/L3A |
| 23.5-25 | 24 | 1615 | 595 | 19.50/2.5 | 12500 | 475 | E3/L3A |
| 26.5-25 | 28 | 1750 | 675 | 22.00/3.0 | 15500 | 475 | E3/L3A |
| 29.5-25 | 28 | 1875 | 750 | 25.00/3.5 | 17500 | 425 | E3/L3A |
| 13.00-24 | 12 | 1350 | 350 | 10.00 | 5600 | 450 | E3/L3A |
| 14.00-24 | 16 | 1370 | 375 | 10.00 | 7300 | 550 | E3/L3A |
| 14.00-25 | 24 | 1370 | 375 | 10.00/1.5 | 9500 | 850 | E3/L3A |
| 16.00-24 | 28 | 1495 | 430 | 11.25/2.0 | 11500 | 750 | E3/L3A |
| 16.00-25 | 28 | 1495 | 430 | 11.25/2.0 | 11500 | 750 | E3/L3A |
| 18.00-24 | 32 | 1615 | 500 | 13.00/25 | 15000 | 750 | E3/L3A |
| 18.00-25 | 32 | 1615 | 500 | 13.00/25 | 15000 | 750 | E3/L3A |
