Big shoulder block pattern with small sipes can avoid uneven wear and effectively reduce the heating up and resonance.
Continuous longitudinal groove design for excellent water drainage, so provide good grip and maneuvering on wet road.
Lateral small sipes design enhance the maneuvering performance.
Use the FEA, Finite Element Analysis, and get a optimized pitch arrangement, displacement to reduce noise.
| SIZE | Load Index | Speed Rating | Standard Rim | Section Width (mm) | Overall Diameter (mm) | Max.load | Max.pressure | U.T.Q.G |
| kg | kpa | |||||||
| 175/60R13 | 77 | T | 5J | 177 | 540 | 412 | 300 | 380AA |
| 165/65R13 | 77 | T | 5.00B | 170 | 544 | 412 | 350 | 380AA |
| 155/70R13 | 75 | T | 4.5J | 157 | 548 | 387 | 300 | 380AA |
| 155/80R13 | 79 | T | 4.5J | 157 | 578 | 437 | 300 | 380AA |
| 155/65R13 | 73 | T | 4.5J | 157 | 532 | 365 | 300 | 380AA |
| 165/70R13 | 79 | T | 5.00B | 170 | 562 | 437 | 350 | 380AA |
| 165/70R13 *wsw | 83 | T | 5.00B | 170 | 562 | 487 | 340 | 380AA |
| 175/70R13 | 82 | H | 5.00B | 177 | 576 | 475 | 350 | 380AA |
| 185/70R13 | 86 | T | 5.50B | 189 | 590 | 530 | 350 | 380AA |
| 185/60R14 | 82 | H | 5.5J | 189 | 578 | 475 | 350 | 380AA |
| 165/65R14 | 79 | H | 5J | 170 | 570 | 437 | 350 | 380AA |
| 175/65R14 | 82 | H | 5J | 177 | 584 | 475 | 350 | 380AA |
| 185/65R14 | 86 | H | 5.5J | 189 | 596 | 530 | 350 | 380AA |
| 165/70R14 | 81 | T | 5J | 170 | 588 | 462 | 350 | 380AA |
| 165/70R14 | 85 | T | 5J | 170 | 588 | 515 | 340 | 380AA |
| 175/70R14 | 84 | T | 5J | 177 | 602 | 500 | 350 | 380AA |
| 185/70R14 | 88 | T | 5.5J | 189 | 616 | 560 | 350 | 380AA |
| 195/70R14 | 91 | T | 6J | 201 | 630 | 615 | 350 | 380AA |
| 175/70R14C | 91/93 | S | 5J | 177 | 602 | 690/1435 | 375 | 380AA |
